SOLAR PV PANEL APESS 580W
SOLAR PV PANEL APESS 580W
Product Code: N580-600M10D
Cells: 120 (half-cut cells)
Junction Box: Detachable junction box, IP68, integrated with 3 bypass diodes
Output Cable: 4mm², +-400, -200mm / +-1400mm, cable length customizable upon request
Glass: Dual glass, semi-tempered, thickness 2.0 + 2.0mm
Frame: Anodized aluminum alloy
Weight: 28 kg
Dimensions: 2278 × 1134 × 30 mm
APESS N580-600M10D Solar PV Module: The Optimal Solution for Sustainable Solar Systems
As the demand for clean energy continues to grow, choosing a solar panel with high efficiency, outstanding durability, and flexible compatibility with a wide range of inverters has become the key factor for every project. APESS provides the ideal answer: the APESS N580-600M10D Solar PV Module.
Superior Efficiency with Half-Cut and N-Type TOPCon Technology
-
Conversion efficiency up to 21.5%
-
Half-cut cell design minimizes energy loss and enhances output
-
Stable performance even under low-light or partial shading conditions
Long-Term Reliability with a Lifetime of up to 30 Years
-
Dual-glass design (2.0 + 2.0 mm) with anti-reflective, impact-resistant tempered glass
-
Anodized aluminum alloy frame for superior corrosion resistance
-
Certified resistance to PID, salt mist, ammonia, and sand
-
IP68 junction box with integrated 3 bypass diodes for enhanced reliability
Optimized for Modern Inverter Systems
-
Fully compatible with a wide range of grid-tied and hybrid inverters, including Afore
-
Voltage and current ratings aligned with inverter input ranges, reducing transmission loss
-
Contributes to system efficiency of up to 98.5%
Comparison with Other PV Modules
| Criteria | APESS N580-600M10D | JA Solar 580W Bifacial | Canadian Solar 585W | Trina Solar 580W |
|---|---|---|---|---|
| Technology | N-Type TOPCon + Half-Cut | P-Type Half-Cut | Monofacial | Monofacial |
| Efficiency (%) | ~21.5% | ~21% | ~20.6% | ~20.5% |
| Performance Warranty | 30 years | 25 years | 25 years | 25 years |
| Real-World Output | 10–20% higher | 5–15% higher | Standard | Standard |
| Price | Competitive | Higher | Mid-range | Mid-range |
Wide Range of Applications
-
Residential solar systems: houses, villas, apartments
-
Agricultural and farm rooftop solar projects
-
Industrial plants and commercial facilities
-
Medium to large-scale EPC projects
Conclusion
The APESS N580-600M10D is not just a solar panel – it is a comprehensive solution that delivers superior efficiency and long-term reliability. With high conversion performance, extended durability, and seamless integration with modern inverter systems, it is the ideal choice for investors aiming to maximize both cost efficiency and long-term benefits.
